執行標準 Executive Standard
本產品按照Q/ZJGG 04-2017設計制造。
The product is manufactured according to Q/ZJGG 04-2017 standard.
用途 Application
本產品主要用于額定電壓450/750V及以下動力裝置線路固定布線。
The products are used for fixed laying in A.C. engine devices, the rated voltage is 450/750V or below.
使用條件
產品具有優異的性能:不含有鹵素，不產生有害氣體及腐蝕性氣體;燃燒時產生煙量較少;不含有鉛等重金屬，不污染土壤。
①電線導體的最高額定溫度是90C;
②電線敷設時的環境溫度不應低于0C;
③最小彎曲半徑:電線外徑小于15mm為6D，15~25mm的為8D， 大于25mm的為10D ( D為電纜外徑)。
交貨長度
產品交貨長度按雙方協定，計量誤差允許不超過土0.5%。
Using Conditions
The product has good performances: non-halogen, won't release harmful
or corrosion gas; low-smoking; do not contain heavy metals, won't cause
soil pollution.
①The maximum temperature of conductor is 90C;
②The ambient temperature should above 0C during installation;
③The bending radius of cable should not less than 6D (D= 15mm), 8D(D=15~25mm), 10D (D>25mm). D is external diameter of cable.
Delivery Length
Delivery length is decided by the seller and buyer, the length deviation is not more than +0.5%.
